Published Apr 23, 2021

Build fluid user experiences with react-spring

Back to blog

I have used react-spring in our design system for more than two years. It provides React Hooks for animated interfaces and fully supports TypeScript.

I find react-spring easier to use than CSS for interactive animation. Its requestAnimationFrame implementation avoids the performance problems of traditional JavaScript animation libraries. Strong community recommendations also make it my first choice for animation in React.

What is a spring?

Read the official Why springs and not durations section for more context.

As its name suggests, react-spring uses a spring model.

CSS animations usually require a timing curve and a duration. A spring instead models physical behavior, which makes fluid, natural motion easier to create.

The official README quotes Andy Matuschak, a former Apple UIKit developer:

Animation APIs parameterized by duration and curve are fundamentally opposed to continuous, fluid interactivity.

In other words, duration and curve parameters do not fit continuous interaction well.

CSS animation can feel awkward in React. With React Transition Group, for example, you must configure animation parameters and matching class names. The useTransition hook provides a direct way to express the same behavior.

API

useSpring

The most basic API is useSpring, which animates transitions between values. Here is a simple example:

function Demo() {
  const [open, setOpen] = useState(false);
  const props = useSpring({ width: open ? 240 : 40 });

  return (
    <animated.div
      style={{
        lineHeight: '40px',
        textAlign: 'center',
        height: 40,
        backgroundColor: 'azure',
        border: '1px solid darkslategrey',
        borderRadius: 8,
        cursor: 'pointer',
        ...props,
      }}
      onClick={() => setOpen((prev) => !prev)}
    >
      {props.width.to((x) => x.toFixed(0))}
    </animated.div>
  );
}

Click the div to animate its width from 40px to 240px. Its children display the current value.

All animated properties returned by react-spring are SpringValue objects. Pass them to an animated.x component when you use them as styles.

The API also supports transitions between string values:

function Demo() {
  const [open, setOpen] = useState(false);
  const props = useSpring({
    transform: open ? 'translateX(100px)' : 'translateX(0px)',
  });

  return (
    <animated.div
      style={{
        lineHeight: '40px',
        textAlign: 'center',
        height: 40,
        width: 60,
        backgroundColor: 'azure',
        border: '1px solid darkslategrey',
        borderRadius: 8,
        cursor: 'pointer',
        ...props,
      }}
      onClick={() => setOpen((prev) => !prev)}
    >
      Item
    </animated.div>
  );
}

Common useSpring examples include expanding a Collapse component and moving a Switch control when its state changes.

This is an official example. See useSpring for API details and more examples.

useSprings

Like useSpring, useSprings animates values. The difference is that it manages an array of springs:

const springs = useSprings(
  number,
  items.map((item) => ({ opacity: item.opacity })),
);

return springs.map((styles) => <animated.div style={styles} />);

This is an official example. See useSprings for API details and more examples.

useTransition

I use useTransition frequently. It animates components or list items as they mount and unmount, making interface changes less abrupt:

function Demo() {
  const [toggle, setToggle] = useState(false);
  const transitions = useTransition(toggle, {
    from: { opacity: 0 },
    enter: { opacity: 1 },
    leave: { opacity: 0 },
  });

  return (
    <div style={{ display: 'flex', height: 40 }}>
      <button style={{ marginRight: 16 }} onClick={() => setToggle((prev) => !prev)}>
        {toggle ? 'Hide' : 'Show'}
      </button>
      {transitions(
        (props, item) =>
          item && (
            <animated.div
              style={{
                fontSize: 40,
                lineHeight: 1,
                ...props,
              }}
            >
              😄
            </animated.div>
          ),
      )}
    </div>
  );
}

This is an official example. See useTransition for API details and more examples.

useTrail

Like useSprings, useTrail manages multiple springs. Each spring follows the previous one instead of starting at the same time.

const trail = useTrail(amount, { opacity: 1 });

return trail.map((styles) => <animated.div style={styles} />);

This is an official example. See useTrail for API details and more examples.

useChain

Use useChain to connect different spring hooks. The next animation starts after the previous animation finishes.

You can also specify a delay between animations. The following code comes from an official example:

const springRef = useSpringRef();
const props = useSpring({ ...values, ref: springRef });

const transitionRef = useSpringRef();
const transitions = useTransition({ ...values, ref: transitionRef });
// Run the transition after the spring animation finishes.
useChain([springRef, transitionRef]);

return (
  <animated.div style={props}>
    {transitions((styles) => (
      <animated.div style={styles} />
    ))}
  </animated.div>
);

Before version 9, this pattern used React useRef. From version 9, use the useSpringRef hook from react-spring.

This is an official example. See useChain for API details and more examples.

config

See Config for the complete parameter list.

You usually do not need to change the configuration. Use a preset when you want a tighter or more relaxed animation:

import { useSpring, config } from 'react-spring';

useSpring({ ..., config: config.stiff });

Each preset changes the motion. The stiff preset makes it tighter. See Presets for other options.

You can also adjust individual parameters. Common choices include:

  • mass: mass
  • tension: tension
  • friction: friction
  • velocity: velocity
  • precision: precision

Traditional easing functions and durations are also supported. See Config for the available parameters.

a11y & testing

Version 9.0.0 introduced Globals.assign to configure react-spring globally.

One useful option is skipAnimation. Set it to true to disable all react-spring animations. This lets you respect a device setting that requests reduced motion.

See Accessibility for more details. Here is an excerpt:

import { useReducedMotion } from 'react-reduce-motion';
import { Globals } from 'react-spring';

const App = () => {
  const prefersReducedMotion = useReducedMotion();

  useEffect(() => {
    Globals.assign({
      skipAnimation: prefersReducedMotion,
    });
  }, [prefersReducedMotion]);
  // ...
};

This option also matters when testing a design system. Tests must check every component, but animations can delay the result of a behavior check.

For example, each Select test can wait for the menu animation. With many tests, those delays accumulate. I previously replaced requestAnimationFrame globally and manually flushed animation frames:

import createMockRaf, { MockRaf } from '@react-spring/mock-raf';

let mockRaf: MockRaf & { flushSpring: () => void };
const raf = window.requestAnimationFrame;
const caf = window.cancelAnimationFrame;

const useMockRaf = () => {
  beforeAll(() => {
    const createdMockRaf = createMockRaf();
    mockRaf = {
      ...createdMockRaf,
      flushSpring: () => mockRaf.step({ count: 32767 }),
    };

    window.requestAnimationFrame = mockRaf.raf;
    window.cancelAnimationFrame = mockRaf.cancel;
  });

  afterAll(() => {
    window.requestAnimationFrame = raf;
    window.cancelAnimationFrame = caf;
  });
};

export { mockRaf, useMockRaf };

Now, add the following configuration to the preload file before your tests:

Globals.assign({
  skipAnimation: true,
});

The tests can then skip all animations.

Final thoughts

There are more APIs to explore, especially after the improvements in version 9. Examples include the imperative API, async animations, and animation events.

Try react-spring when your project needs animation. Its simple API and natural motion make it a useful option.
